Tuesday, 26 November 2019

Steam Heating (3)

Following on from Steam Heating (2), I've fitted the carriage warming equipment to Sentinel 7109 ready for a steam test with a train in a few days time.

I began with the boiler connection and isolating valve.
Isolating valve plumbed into the boiler orifice
Having removed the boiler orifice plug and cleaned out the threads, I checked the 1/2" BSP thread type using a parallel tapping tool. The thread was clearly a parallel type and the BSPT tapered thread of the hex nipple was loose unless tightened firmly. This was as expected so I converted the thread to a tapered type using a tapered tapping tool. Now the BSPT tapered thread of the hex nipple fitted much more positively.

I completed the joint using Rocol steam seal. Total loco unavailable time: about half an hour!

I then fitted the standard buffer beam equipment using the purpose-designed flange.
Standard buffer beam equipment fitted to buffer beam (1)
Standard buffer beam equipment fitted to buffer beam (2)
The blue Spirax Sarco Pressure Reducing Valve (PRV) and Safety valve assembly came next followed by the flexible hose to link the isolating valve to the buffer beam equipment.
Blue PRV and safety valve attached to rear of flange (1)
Blue PRV and safety valve attached to rear of flange (2)
Also showing above is the narrow copper pipe to link the buffer beam outlet pressure to the gauge on the cab's rear panel near the roof on the fireman's side.
Steam Heating Pressure Gauge
The weight of the PRV assembly is supported by a clamp between the PRV and safety valve linked to the footplate above by M10 studding.

Having fitted the buffer beam equipment and attached the hose, I hitched up the hose end using the standard support links. It then became obvious that the assembly was somewhat lower than expected. On examining a MK1 carriage for comparison, the assembly is 6 to 8 inches lower.
Hitched with shortened support linkage
To avoid the end dragging on the ground or catching the rails, by wiring the two end parts of the support links together, I've pulled it up to a safe height above the rails as shown above. A more permanent version will be devised in due course.

Prior to steaming, the first test was to to check that the lower height would not prevent a connection being made to a carriage. As shown below, it is all OK.
May be low but fits perfectly.
Now all we need to do is a steam test. I anticipate that the carriages will be too cold, too hot or somewhere in between. If these are the pass criteria, then all should be fine!


Wednesday, 13 November 2019

Steam Heating (2)

After some pretty hectic weeks, I have most of the sub assemblies ready to fit. Rapid progress has been made possible by Amanda and Rob at South West Engineering Supplies at Bumpers Farm industrial estate near my home in Chippenham. Without them, I'd have been struggling to obtain all the bits and pieces in a short time and they have given me ready access to trial and error items. So a big thank you to them.

Following on from 'Steam Heating (1)', this is how it's developed.

What equipment is needed?

1. High pressure pipework and an isolating valve able to withstand the Sentinel boiler temperature & pressure (212DegC & 275psi).
High Pressure Pipe Fittings and Valve
In the photo above, the steel 'T' fitting's leg links to a 3000psi stainless steel union and thence to a taper threaded hex nipple which will screw into the boiler orifice. This union allows the angle of the 'T' to be set after securely fixing the nipple into the boiler orifice. The plug at the top of the 'T' fitting is to provide another steam outlet for future use.

The second union below the 'T' fitting allows the valve to be orientated appropriately. The valve is a three-part ball valve made by Valtac. I've written about these before. The hex nipple below the valve will connect to flexible braided hose to take the steam down to the buffer beam. Although the nipple in the photo is a steel type, I will be using a parallel threaded hydraulic fitting machined to take a copper washer sealed mating connector.

2. Pipework to carry the boiler pressure steam to the buffer beam apparatus.

Purists might criticise me for using modern flexible stainless steel braided hose instead of copper pipe with braized end fittings. I can order and receive the flexible hose with welded end fittings and a pressure test certificate within a week and be confident in the result. Using copper pipe, I cannot do this. (In fact, the hose arrived in four days!).

I've covered this before in detail here.

3. A pressure reducing valve to take the boiler pressure down to the carriage requirements (about 40psi).
Blue Pressure Reducing Valve (centre) (and one assistant)
Blue Pressure Reducing Valve (and other assistant)
The blue Spirax Sarco PRV is a 1/2" BRV2S with a Green Spring to allow a range of 20-60psi.

Arguably, to reduce the length of high pressure hose, I could have put the pressure reducing valve below the ball valve instead of behind the buffer beam. However the PRV needs to be mounted upright and would have taken up too much space in the cab.

4. A safety valve to prevent exceeding the carriage maximum pressure.
Gunmetal Safety Valve
The safety valve is a 1/2" ART 642 type made by Albion.
Safety Valve Detail including 3 bar setting.
5. A pressure gauge to allow the carriage pressure setting.
3" Steam Pressure gauge
The safety valve has been delivered certified to 45psi (3 bar) so 100psi full-scale is fine. I purchased it new from "thegaugeman61" on Ebay".

6. Heavy duty bracketry to fix the pipework and standard buffer beam equipment to the buffer beam itself.
Flange made to fit the standard buffer beam equipment to the buffer beam
The flange's central hole is tapped to 1.25" BSPT (tapered) to take a 1.25" section of pipe. The pipe section is then held by a Stauff clamp with an add
itional supporting bar screwed to the bottom edge of the buffer beam. A third bolt fixes the flange through the buffer beam. It is pretty strong and intended to survive heavy handling.
The flange 3-point mounting to the rear buffer beam
The Complete Assembly

I've pre-assembled the 'flat-pack' version of the equipment to show it all together before it disappears out of sight in and under Joyce's metalwork.
Complete 'flat-pack' and assistants
The boiler fitting is at the top. It passes steam via a 'T' fitting to a ball valve and thence to the braided flexible hose. The hose links to the blue PRV which passes lower pressure steam to the safety valve and pressure gauge pipe. Finally the pipe connects to the back of the flange and to the standard buffer beam equipment.

Now all I have to do is fit the kit and test it. Initial fitting will be quite quick for test purposes. I'll clamp the pipework properly when I'm happy it performs satisfactorily. The assistants will not be allowed on site at Midsomer Norton as they haven't passed their Personal Trackside Safety exam (honest!).

Thursday, 10 October 2019

Steam Heating (1)

Carriage Warming Steam Hose link
I've been asked by the Somerset & Dorset Joint Railway Co. Ltd. to fit steam heating, aka carriage warming equipment, to the cab end of Sentinel 7109 'Joyce'. I'm slightly bothered by the idea as the gear involved will take up even more of the already limited cab space. However, I will give it my best shot, hopefully in time for the cooler weather coming on.

There are some critical feasibility questions:

  • How much steam is required?
  • Does the boiler have the capacity?
  • Where can I tap-off the steam supply?
  • What size of pipework is needed?
  • What equipment is needed?
  • How to minimise the out-of-service time during installation?
  • How to ensure the installation is safe?
  • How do I test it?
How much steam is required?

In 2014, the Heritage Railway Association (HRA) produced a Steam Heating Apparatus guidance note which I am using as the authoritative document. It states the following:

"Most steam heated coaching stock contains thermostatically controlled heaters which limit the steam consumption once the heater has reached working temperature. Because of this and the reduced length of trains now running, a pressure of 40psi is sufficient to maintain a flow to the end of a rake of vehicles. Allow about 80-100lbs of steam per hour per carriage to heat a train."

As a worst case, I'll assume Joyce will need to provide 100lbs of steam per hour per carriage.

At Midsomer Norton, Joyce is generally limited to two carriages although she could encounter more if operated elsewhere. I am thus basing calculations on three carriages and deem the requirement to be 300lbs/hour.

Does the Boiler have the Capacity?

Joyce's boiler has the capacity to produce 4600lbs/hour. Thus only about 6.5% of the boiler output would be used when supplying the 300lbs/hour to the carriages. I doubt if Joyce would notice this and if it did hold her back, the heating could always be turned off while climbing the 1 in 50 hill from the station, usually for about 5-7 minutes.

Where can I tap-off the steam supply?

Joyce's entire boiler output has to be able to be passed through the safety valves. The manifold which supports the safety valves is fed through a 3/4" diameter orifice. This means that 4600lbs/hour can pass through a 3/4" orifice.

There are two 1/2" diameter plugged orifices near the top of Joyce's boiler, one on the left and the other on the right hand side. A 1/2" orifice has 4/9ths of the area of a 3/4" orifice. Thus it is easy to say that 300lbs/hour will have no difficulty with a 1/2" orifice.

I plan to use the left side orifice as it will allow the fireman to control the heating. I will also use a plugged 'T' pipe fitting to make it simpler to add a steam wand later.

There are some other options I dismissed:

1. The super-heater input manifold at the front of the boiler. This would require removing the coal bunker to get access and would put an isolating valve out of the reach of the footplate crew.

2. The regulator assembly. This would have supplied super-heated steam complete with cylinder oil - I'm not sure how hot the passengers really want to be in cold weather!

3. The right hand 1/2" orifice. This would add to the already heavily populated driver's side of the cab and it's really the fireman that should be in control.

4. The safety valve manifold/fittings. Same as in 3 above but could well make for a lengthy down-time during installation and require the disturbance of well proven installed items.

Note: references to 1/2" or 3/4" are to nominal inside pipe diameters and the BSP thread size.

What size of pipework is needed?

Using a 1/2" boiler orifice indicates that 1/2" pipework will be adequate and it is good news as 1/2" pipework won't fill too much of the limited cab space.

I was surprised at this but the figures tell the story. However, as we are only allowing for 3 carriages, not 14 or so as might have been the case in the days of British Railways steam, I am convinced 1/2" pipework will be fine.

What equipment is needed?

I'll cover this in a subsequent article as it will be quite extensive.

How to minimise the out-of-service time during installation?

The only part of the installation work that will actually make Joyce unusable is when making the steam connection to the boiler. The rest of the apparatus can be fitted to Joyce before making the boiler connection without disturbing the ability to operate.

How to ensure the installation is safe?

The critical part of the apparatus is the link from the boiler orifice to an isolation valve fitted as close as possible to the boiler.

Either a male parallel threaded fitting sealed with a Copper washer will be used to connect to the parallel female thread of the boiler orifice or, preferably, both tapered male and female threads as they lock more effectively. Tapered male threads with parallel female threads are not suitable for this application as they have a limited contact area with the female thread and are not as strong.

Heavy duty forged steel or 3000psi Stainless steel fittings will be used where full boiler pressure is involved. Malleable iron fittings will be used at carriage pressure.

'Red-band' grade steel pipe or braided/annularly corrugated flexible hose or a combination of both will be used.

The isolation valve will be of the same type used for the vacuum ejector isolator, whistle/pressure gauge isolator and blown-down valve. These are high grade carbon fibre reinforced PTFE-sealed stainless steel ball valves as previously described here.

How do I Test it?

I'm not planning any special equipment to test the new apparatus. Instead, it will be a matter connecting Joyce to a three carriage train and trying out various functions.

1. With the hose link valve closed so that steam cannot leave the loco, initially turn on the isolator valve; the out-going pressure should not exceed 45psi. A safety valve should open to prevent it going higher than 45psi (3 bar).

The pressure reducing valve's pressure control should be varied to show that the outgoing pressure can be set as desired. (It may not be possible to do this without a flow of steam. If this is the case then it should be done carefully with the valve to the carriages open).

2. If not already done so, open the valve to the train and check the loco can supply the required pressure to the three carriages when all their heaters are set to maximum.

3. Check that the set pressure can be maintained with the boiler pressure between 100 and 275psi. Experience with the vacuum brake ejector pressure reducing valve suggests that as the boiler pressure reduces, the outlet pressure may rise but not above the safety valve setting.

Wednesday, 7 August 2019

Improved Oiling for the inter-axle Chain

Whilst I've written extensively about Sentinel 7109's front drive chains, I've said very little about the chain which links the two axles. It does the job more conventionally performed by connecting rods. The chain was in place when Joyce arrived in 2004 and I've largely just left it to get on with its job.
Highlighted original oil pot and down-pipe with wipe-rag
Oiling the chain was originally done by gravity. A pot fed oil down a tube to the chain via a rag which wiped oil on the links as they moved past.

The oil pot was another example from Joyce's missing items portfolio so I had to construct a new one. I used the end section of a small argon gas cylinder and added a valve to turn the flow on and off.

These items are hidden in the photo below beneath an upturned metal cover (OK, it's a bean can but it was a perfect fit!). The down-pipe is original but the new rag was a hem extracted from an old pair of jeans.
Gravity-fed oil feed
In so far as it went, it could do the job just about adequately but I was forever either forgetting to turn it on before moving off or leaving it on when stopped so one link got deluged and the rest left dry. (Perhaps the original pot used a wick?). What was really needed was a similar system to the front drive chains such that oil would only be provided when moving.
Being driven by the engines, the mechanical lubricator was an ideal candidate but its four pump barrels were already allocated.
Mechanical Lubricator (before restoration)
In the above view, the right hand pump feeds the near-side drive gear bearing and the next one feeds the off-side drive gear bearing. The third from right feeds the steam supply and the left hand one feeds the front chains via a pair of drip trays.
Drip trays and drip feed tubes
Initially I thought that the mechanical lubricator was out of bounds but experience showed that a good supply of oil was already being fed through the drive gear bearings into the drip trays without any additional oil required from a dedicated pump. Thus the left-most pump was effectively a spare.

In the back of my mind has always been the thought that 7109 was a prototype and thus some parts/methods of operation were possibly experimental and not well tried and tested; they could thus be improved.
Oil from the gear bearings into the drip tray
I set out to construct a feed from the mechanical lubricator to the inter-axle chain. My plan was to suspend a three-drip device above the chain and connect it by a pipe to the lubricator.

A number of parts needed to be made:

1. An adaptor to connect a pipe to the lubricator pump.
2. The pipe itself (I chose to cheat and use rubber fuel hose).
3. The three-drip device.
4. Rigid support for the feeder so it wouldn't shake it all about.

The adaptor seemed an easy task: it would be needing BSP threads obviously? No it wouldn't! To cut a long story short, it needed a rare British Standard Cycle thread as used on push-bikes and motor bikes. The thread was actually 3/4" 20tpi and taps and dies were surprisingly easy to obtain (Ebay).
The rubber hose adaptor rightmost
The adaptor consists of a coupling with a female 3/4" BSC thread end to end and a plug screwed into the top. The plug is tapped for a standard 1/8" BSP hose adaptor. The coupling is screwed on to the pump first. The plug seals against the top of the pump with a fibre washer. Heldite was used to seal the hose adaptor.
Three-drip device
I wanted to be able to set the three-drip device so that it would dribble on the left and right links of the chain as well as centrally on the rollers. Thus it would be required to be able to be rotated to get the drippers the right distance apart and in the right place.

Any resemblance in the body of the device to a Lidl compressed-air adaptor are purely coincidence of course (but it saved a lot of work for very little cost!).
The dripper attached to an angle-iron support
The complete dripper support
I made the rigid support using a pair of Stauff clamps to fix a vertical piece of 1.25" steel pipe (same as used for the vacuum braking pipework) to the front of the water tank inside the engine compartment.
Pipe clamped to the water tank
I then attached the angle iron support bracket to the pipe with another Stauff clamp.
Viewed from underneath
Stauff clamps grip the pipe very tightly and the dripper is held very robustly in place.
Not an easy photo so take (apologies for low quality)
The rubber pipe is supported in a fairly low-tech manner.
Rubber pipe routing
After a lengthy non-trivial design and installation task, I tried it out on a passenger operations day. It certainly works and there is now no shortage of oil for the drive and inter-axle chains and one less job to do when preparing to steam. There is still a good deal of fiddling about to do yet to get the flow rates right, not helped by the newly sorted central heating for the mechanical lubricator. The oil is now warmer and thinner as a result and the pumps provide more oil than before.

One question I don't have the answer to is how much oil does a chain need? I haven't oiled my mountain bike's chain for years and it is still happy; however, these chains work a little harder than my bike's so sufficient will be enough.

I'm also hoping to reduce the oil consumption. 7109 uses about 3 pints of cylinder oil a day - that seems a lot to me.

I'll remove the old gravity-feed oiler when all is set up satisfactorily.

Grate Solution to a Problem

Not widely known but just before the press were due to arrive on a steaming day recently, Joyce's firebox centre firebar dropped into the ashpan - not really what's wanted with little time to put it right and in the middle of a raging furnace!
Complete Firegrate;
However, miracles can be performed when there is no choice and the fireman of the day managed to put it back in place and all was well.

It's easier to empty ash/clinker from the grate by removing a firebar but getting it back in isn't easy without crawling underneath (ideally with the ashpan removed)(decidedly not my favourite activity).
It's Grate
Although it won't be much help with replacing a dropped firebar under a hot fire, I've made a tool for putting them back through the firehole after emptying the grate when cold.

One end fits through a firebar slot and the curved end is for twisting the firebar into position.
